Wurth Electronics Inc. 744305022

Name: 744305022
Brand: Wurth Electronics Inc.
SKU: 744305022
Price: 1.1328 USD
Availability: InStock
Rating: 4.9 (710 reviews)

MFG Part Number: 744305022

Available Quantity: 17180 Pieces

Reference Price: USD 1.1328

Our Price: We have a big discount, please contact us

Shipping Date: We can ship out today

Manufacturer: Wurth Electronics Inc.

Brief Description: WE-HCM FIXED Inductors 220NH 26A 0.155 MOHM

Lead Free Status / RoHS Status: RoHS Compliant (Lead Free)

Moisture Sensitivity Level (MSL): 1 (Unlimited)

Date Code (D/C): New

Product Category: Fixed Inductors

Stock Resource: Franchised Distributor

Warranty: 360 days quality guarantee

Datasheet: 744305022.pdf

Request Quotation for 744305022

Company Name

Contact Person

Phone Number

Address

Email

Message

744305022 Specifications

Manufacturer Part Number	744305022
Future Part Number	FT-744305022
SPQ / MOQ	Contact Us
Packing Material	Reel/Tray/Tube/Others
Series	WE-HCM
744305022 Status (Lifecycle)	In Stock
Part Status	Active
Type	Wirewound
Material - Core	Manganese Zinc Ferrite
Inductance	220nH
Tolerance	±20%
Current Rating	26A
Current - Saturation	42A
Shielding	Shielded
DC Resistance (DCR)	0.155 mOhm
Q @ Freq	-
Frequency - Self Resonant	600MHz
Ratings	-
Operating Temperature	-40°C ~ 125°C
Inductance Frequency - Test	100kHz
Features	-
Mounting Type	Surface Mount
Package / Case	Nonstandard
Supplier Device Package	-
Size / Dimension	0.531" L x 0.524" W (13.50mm x 13.30mm)
Height - Seated (Max)	0.205" (5.20mm)
Country of Origin	USA/JAPAN/MALAYSIA/MEXICO/CN
744305022 Weight	Contact Us
Replacement Part Number	744305022-FT
