Everlight Electronics Co Ltd EL2630-V
- MFG Part Number
- EL2630-V
- Available Quantity
- 52030 Pieces
- Reference Price
- USD 1.864
- Our Price
- We have a big discount, please contact us
- Shipping Date
- We can ship out today
- Manufacturer
- Everlight Electronics Co Ltd
- Brief Description
- - OPTOISO 5KV OPEN COLLECTOR 8DIP
- Lead Free Status / RoHS Status
- RoHS Compliant (Lead Free)
- Moisture Sensitivity Level (MSL)
- 1 (Unlimited)
- Date Code (D/C)
- New
- Product Category
- Optoisolators - Logic Output
- Stock Resource
- Franchised Distributor
- Warranty
- 360 days quality guarantee
- Datasheet
- EL2630-V.pdf
EL2630-V Specifications
| Manufacturer Part Number | EL2630-V |
|---|---|
| Future Part Number | FT-EL2630-V |
| SPQ / MOQ | Contact Us |
| Packing Material | Reel/Tray/Tube/Others |
| Series | - |
| EL2630-V Status (Lifecycle) | In Stock |
| Part Status | Active |
| Number of Channels | 2 |
| Inputs - Side 1/Side 2 | 2/0 |
| Voltage - Isolation | 5000Vrms |
| Common Mode Transient Immunity (Min) | 5kV/µs |
| Input Type | DC |
| Output Type | Open Collector |
| Current - Output / Channel | 50mA |
| Data Rate | 10Mbps |
| Propagation Delay tpLH / tpHL (Max) | 100ns, 100ns |
| Rise / Fall Time (Typ) | 40ns, 10ns |
| Voltage - Forward (Vf) (Typ) | 1.4V |
| Current - DC Forward (If) (Max) | 20mA |
| Voltage - Supply | 7V |
| Operating Temperature | -40°C ~ 100°C |
| Mounting Type | Surface Mount |
| Package / Case | 8-DIP (0.300", 7.62mm) |
| Supplier Device Package | 8-DIP |
| Country of Origin | USA/JAPAN/MALAYSIA/MEXICO/CN |
| EL2630-V Weight | Contact Us |
| Replacement Part Number | EL2630-V-FT |
